Model 1217P – DC limit style

Model 1217P – DC limit style

Model 1217P – DC limit style

The 1217P is an inductive proximity sensor that features 10-40VDC voltage, 150 pulses/sec and 100 mA rating.

Input

Voltage: 10-40VDC
Frequency: 150 pulses/sec

Output

Rating: 100 mA

Timing

Indication: LED

Physical

Operating Temp: -25° to 50° C (32° to 120° F)

Sensing

Sensing Distance:: 0.5 inch (12.7mm)
