Model 1310 Din Rail Mount
True Off Delay
Din Rail Mount
Continuous Duty
Reset Button
Remote Reset with built in LED Indicator
The 1310 is a control-on delay, built specifically for continuous duty operation..
For electric utility applications capable of high voltage DC switching. Din-Rail mounted housing with finger-safe electrical connectors – IP20 Rating. Reinforced Isolation Relay (Sealed Relays) Timed and Instantaneous contacts
General Characteristics
Product Sheet
Input
Voltage: 18 to 72 VAC/DC, 90 to 300 VAC/ 120 to 320 VDC, 80 to 160 VAC / 45 to 155 VDCPower Consumption: 6W maximum
Transient Protection: TVS
Output
Type: Electromechanical RelayRating: 10A @ 28 VDC (MAX); 3A @ 37 VDC; 0.5A @ 100 VDC; 0.4A @ 150 VDC; 0.3A @ 300 VDC; 10A @ 250 VAC (MAX)
Timing
Timing Function: Control On-DelayRepeat Accuracy: +/- 1% of setting
Reset Time: 0.1 seconds minimum
Indication: LED
Range Tolerance: ≤ 10%
Physical
Operating Temp: -30° C to +73.9° C (-22° to 165° F)Timing Variation vs. Temp: +/- 20% maximum
Mounting: Din-Rail 35mm
Termination: Finger-safe connectors - IP20 Rating
Housing: Plastic - Polycarbonate
